Schulz v-series 5hp 80 gallon-20 cfm- single phase 230 volts-two-stage air compressor 20 cfm 580vv20x-1 vertical
Product details
| Management number | 238357211 | Release Date | 2026/07/11 | List Price | US$1,440.00 | Model Number | 238357211 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
<ul><li> \n </li><li>WEG Electric Motor</li><li> \n </li><li><strong><u>SCHULZ AIR COMPRESSOR 7.5HP SINGLE PHASE 208-230 VOLTS</u></strong></li><li> \n </li><li>5 HP motor reliably handles commercial duty demands</li><li> \n </li><li>V-Series Cast Iron Pump</li><li> \n </li><li>Runs cooler, lasts longer due to the space between each cylinder</li><li> \n </li><li>Deeper cylinder fins for additional heat dissipation</li><li> \n </li><li>Oversized Main Bearings</li><li> \n </li><li>Sturdy & reliable</li><li> \n </li><li>Swedish Steel Valves</li><li> \n </li><li>Quality components contribute to pump efficiency</li><li> \n </li><li>CNC Machined Components</li><li> \n </li><li>Accurate fit produces top-notch performance</li><li> \n </li><li>Notched Belts Standard</li><li> \n </li><li>Enclosed belt guard protects the belt & operators</li><li> \n </li><li>Powder Coated Components</li><li> \n </li><li>Resist rust & corrosion</li><li> \n </li><li>1 Year Unit With 2 Year Pump Warranty</li><li> \n </li><li>Protects your investment \n<div> \n<div> \n \n \n \nProduct Category \nAir Compressor - Stationary \n \n \n \n \n \n<strong><em>MOTOR</em></strong> \n \n \n \nVoltage \n230 Volt AC \n \n \nPhase \nSingle Phase \n \n \nMagnetic Starter \nYes \n \n \nAmp Draw \nConsult Certified Electrician \n \n \nRecommended Breaker \nConsult Certified Electrician \n \n \n \n \n \n<strong><em>ENGINE</em></strong> \n \n \n \nHP \n5 \n \n \n \n \n \n<strong><em>PUMP</em></strong> \n \n \n \nCFM \n20 \n \n \nCFM Rated @ \n175 PSI \n \n \nPump Material \nSolid Cast Iron \n \n \nMax PSI \n175 PSI \n \n \nOil Sight Glass \nYes \n \n \nPump Type \nTwo-Stage \n \n \nAfter Cooler \nNo \n \n \nPump Drive \nBelt Drive \n \n \nOil Type \nOil Lubricated \n \n \nOil System \nSplash Lubricated \n \n \nPump Low Oil Shut-off \nNo \n \n \n \n \n \n<strong><em>TANK</em></strong> \n \n \n \nTank Size \n80 Gallons \n \n \nTank Outlet \n1/2 Inch \n \n \nElectronic Drain Valve \nNo \n \n \nTank Orientation \nVertical \n \n \n \n \n \n<strong><em>ACCESSORIES</em></strong> \n \n \n \nPressure Gauge \nYes \n \n \nAir Dryer \nNo \n \n \n \n \n \n<strong><em>OVERVIEW</em></strong> \n \n \n \nProduct Category \nAir Compressor - Stationary \n \n \nWeight \n480 Pounds \n \n \nCertification \nASME \n \n \nConsumer Warranty \n1 Year \n \n \nCommercial Warranty \n1 Year \n \n \nProduct Length \n31.5 Inches \n \n \nProduct Width \n25.2 Inches \n \n \nProduct Height \n78 Inches \n \n \nPower Type \nElectric \n \n \n \n \n \n</div> \n</div></li><li> \n</li></ul> \npart # 932.9339-0 \n \n580VV20X-1 \n<div></div> \n<div> \n<div></div> \n</div> \n<div>QUESTION 770-734-6383</div>
Schulz v-series 5hp 80 gallon-20 cfm- single phase 230 volts-two-stage air compressor 20 cfm 580vv20x-1 vertical| Cfm | 20 |
|---|---|
| Volume capacity | 80 gal |
| Horsepower | 5 HP |
| Maximum psi | 175 psi |
| Air compressor tank type | Vertical |
| Brand | schulz |
| Features | Stationary |
| Volts | 230 V |
| Electrical phase | Single Phase |
| Accessories | Pressure Gauge |
| Material | Cast Iron |
| Weight | 650 lb |
| Model | 580VV20X-1 |
| Assembled product height | 80 in |
